5 Way Ball Valve

Home > 5 Way Ball Valve

Ayhan Tube Fittings, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of **5 Way Ball Valves**. They specialize in delivering high-quality solutions for intricate fluid control and distribution in various industrial and process systems. Renowned for their precision engineering and sturdy construction, these valves offer flexible flow routing, dependable operation, and leak-free performance, even in high-pressure, high-temperature, and corrosive environments. Built to meet international standards, Ayhan’s valves guarantee safety, efficiency, and long-lasting durability. Thanks to their advanced production methods and a strong focus on customer satisfaction, Ayhan Tube Fittings has built a solid reputation for providing 5-way ball valves for critical industrial needs.

5 Way Ball Valve Supplier In İzmir, 5 Way Screwed End Ball Valve Exporter In Istanbul, 5 Way Threaded Ball Valve Dealer In Ankara, 5 Way Butt Weld Ball Valve Supplier in Istanbul, 5 Way Socket Weld Ball Valve Price List in Ankara, ANSI B 16.5 Ball Valve Manufacturer in İzmir, ASTM A 216 GR. WCB Ball Valve in Antalya, ASTM A351 Gr. CD4Mcu Ball Valve Exporter in Ankara, ASTM A 351 GR. CN7M Ball Valve Manufacturer in Bursa, 4 Way Ball Valve In Istanbul, Turkey.

These 5 Way Ball Valves are crafted from top-notch materials like stainless steel, carbon steel, Monel, and nickel alloys, ensuring outstanding corrosion resistance, mechanical strength, and dimensional stability. They deliver precise flow control, smooth operation, and reliable sealing, making them leak-proof even in the toughest industrial and process settings. Their robust design means they require minimal maintenance and have a long service life, making them perfect for complex piping systems.

Specification of 5 Way Ball Valve

Design Standard	BS EN ISO 17292 (BS 5351) / BS EN ISO 12516 / BS EN 1983 / ASME B 16.34 / API 6D
Inspection & Testing Standard	BS EN ISO 12266 – I (BS 6755 – I)
Flange To Flange Distance	Mfg. Standard
End Connection	Flanged End to ANSI B 16.5, Class 150 / 300
	BS 10 Table D / E / F / H
	PN 6 / PN 10 / PN 16 / PN 25 / PN 40
	DIN Standard / JIS Standard / IS Standard
Manufacturing Size Range	1/2″ (DN15) to 6″(DN 150)
Pressure Rating of Valve	150# / 300#
	PN 10 / PN 16 / PN 25 / PN 40
Valve Operation	Manual Hand Lever / Worm-Gear Actuator Operated
	Pneumatic Rotary Quarter Turn Actuator / Electrical Actuator

5 Way Ball Valve Supplier In İzmir, 5 Way Screwed End Ball Valve Exporter In Istanbul, 5 Way Threaded Ball Valve Dealer In Ankara, 5 Way Butt Weld Ball Valve Supplier in Istanbul, 5 Way Socket Weld Ball Valve Price List in Ankara, ANSI B 16.5 Ball Valve Manufacturer in İzmir, ASTM A 216 GR. WCB Ball Valve in Antalya, ASTM A351 Gr. CD4Mcu Ball Valve Exporter in Ankara, ASTM A 351 GR. CN7M Ball Valve Manufacturer in Bursa, ANSI B 16.5 Ball Valve In Istanbul, Turkey.

Top 5 Way Ball Valve Manufacturing Company in Istanbul

At Ayhan Tube Fittings, we are the largest supplier, manufacturer, and exporter of 5 Way Ball Valve in Istanbul, Turkey. Our advanced manufacturing facilities, strategically positioned in the Turkey, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands

Materials List for 5 Way Ball Valve

Item	Part Name	Material	Qty
1	Body	A351 Gr. CF8M	1
2	End Cap	A351 Gr. CF8M	3
3	Blind End Cap	A351 Gr. CF8M	1
4	Ball	316SS	1
5	Stem	316SS	1
6	Seat	RTFE ( 15% C.F.)	4
7	Body Seal	PTFE	4
8	Body Bolt	304SS	16
9	Body Bolt Washer	304SS	16
10	Thrust Washer	PEEK	1
11	Stem O-Ring	Viton 90	1
12	Stem Packing Set	TFM	1
13	Packing Gland	304SS	1
14	Belleville Washer	301SS	4
15	Gland Nut	304SS	1
16	Gland Nut Lock Washer	304SS	1
17	Stop Pin	304SS	1
18	Stop Plate	304SS	1
19	Handle	304SS	1
20	Handle Nut	304SS	1
21	Handle Cover	Vinyl	1
22	Trunnion Bearing	PEEK	1
23	Trunnion Bolt	304SS	3
24	Trunnion	316SS	1
25	Trunnion Gasket	PTFE	1
26	Stem Set Pin	316SS	1

Types of 4 Way Ball Valve

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

5 Way Ball Valve Supplier in Istanbul, Turkey

You’ll find 5 Way Ball Valves in a variety of industries, including chemical processing, petrochemical, oil and gas, pharmaceuticals, power generation, and water treatment. They play a crucial role in directing and managing fluid flow, integrating multiple piping paths, and ensuring the safe and efficient operation of pipelines and process systems. With their versatility, reliability, and durability, 5-way ball valves are essential for applications that demand complex flow management, high performance, and long-term operational safety.

5 Way Ball Valve Uses

A 5-way ball valve is widely used in various industries due to its versatile flow control capabilities. Common applications include chemical processing, where it directs the flow of corrosive substances, and HVAC systems for regulating heating and cooling fluids. In oil and gas, it facilitates multi-directional flow management and isolation of pipelines. Additionally, it is used in water treatment facilities for effective flow distribution and in manufacturing processes requiring precise fluid control. Its ability to connect multiple lines enhances efficiency and reduces system complexity in these applications.
