Adjustable Locknut Elbow

Home > Adjustable Locknut Elbow

Ayhan Tube Fittings, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of **Adjustable Locknut Elbows**. They specialize in providing high-quality solutions for flexible and secure piping connections in both industrial and instrumentation systems. Renowned for their precision engineering and sturdy construction, the company crafts adjustable locknut elbows that guarantee leak-free operation, dependable performance, and impressive durability, even in high-pressure, high-temperature, and corrosive environments. Built to meet international standards, these fittings ensure operational safety, efficiency, and consistent performance. Thanks to their advanced production techniques and a strong focus on customer satisfaction, Ayhan Tube Fittings has earned a solid reputation for delivering adjustable locknut elbows for critical piping applications.

45 Degree Hydraulic Adjustable Elbow Supplier in Istanbul, 45 Degree Swivel Elbow Price List in Ankara, C.s Adjustable Elbow Stand Pipe Manufacturer in İzmir, Din Swivel Elbow In Antalya, Male Jic X Female Swivel Elbow Exporter in Ankara, Ss Swivel Adjustable Elbow Manufacturer in Bursa, Cs Swive Elbow In Istanbul, Turkey.

These Adjustable Locknut Elbows are made from top-notch materials like stainless steel, carbon steel, Monel, and nickel alloys, which provide outstanding corrosion resistance, mechanical strength, and dimensional stability. They allow for precise angular adjustments, reliable sealing, and secure connections, ensuring leak-proof performance in piping and instrumentation systems. Their robust design facilitates smooth installation, requires minimal maintenance, and promises a long service life, making them perfect for demanding industrial and process environments.

Adjustable Locknut Elbow Specifications

STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	MS, CS, SS 304, SS 304L, SS 316, SS 316L, SS 316TI ( 1.4571), BRASS, COPPER, DUPLEX, SUPER DUPLEX, INCONEL, MONEL, HASTELLOY, 904L, 6MO, TITANIUM, ALUMINUM, ALLOY 20
MATERIAL
SERIES	LL- LOW PRESSURE, L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
BODY TYPE	FORGED, BAR STOCK
ACCESSORIES	O-RING, DOWTY SEAL, COPPER WASHER, ED SEAL, CUTTING RING, NUT
O-RING & SEALS	NBR ( -35C TO 100 C ) VITON (-25C TO 200 C) , PTFE – (-60C TO 240)
SURFACE	CARBON STEEL -TRIVALENT ZINC PLATED, YELLOW PLATTING, BLACK PHOSPHATE,
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	STEEL – (-40* C TO 120C) ,STAINLESS STEEL – (-60C TO 400C) BRASS – (-60C TO 175*C)

Top Adjustable Locknut Elbow Manufacturing Company in Istanbul

At Ayhan Tube Fittings, we are the largest supplier, manufacturer, and exporter of Adjustable Locknut Elbow in Istanbul, Turkey. Our advanced manufacturing facilities, strategically positioned in the Turkey, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Adjustable Locknut Elbow

Adjustable Locknut Elbow Technical Data

Series	Tube ?D1	F1	F	L	A	L1	P
L	6	14	12	27	12	26	M 12 x 1.5
light	8	17	12	29	14	27.5	M 14 x 1.5
PN 315	10	19	14	30	15	29	M 16 x 1.5
	12	22	17	32	17	29.5	M 18 x 1.5
	15	27	19	36	21	32.5	M 22 x 1.5
	18	32	24	40	23.5	35.5	M 26 x 1.5
PN 160	22	36	27	44	27.5	38.5	M 30 x 2
	28	41	36	47	30.5	41.5	M 36 x 2
	35	50	41	56	34.5	51	M 45 x 2
	42	60	50	63	40	56	M 52 x 2
S	6	17	12	31	16	27	M 14 x 1.5
heavy	8	19	14	32	17	27.5	M 16 x 1.5
PN 630	10	22	17	34	17.5	30	M 18 x 1.5
	12	24	17	38	21.5	31	M 20 x 1,5
	14	27	19	40	22	35	M 22 x 1.5
PN 400	16	30	24	43	24.5	36.5	M 24 x 1.5
	20	36	27	48	26.5	44.5	M 30 x 2
	25	36	36	54	30	50	M 36 x 2
	30	50	41	62	35.5	55	M 42 x 2
PN 315	38	60	50	72	41	63	M 52 x 2

45 Degree Hydraulic Adjustable Elbow Exporter in Istanbul, C.s Adjustable Elbow Stand Pipe Price List in Ankara, 45 Degree Swivel Elbow Manufacturer in İzmir, Din Swivel Elbow In Antalya, Male Jic X Female Swivel Elbow Supplier in Ankara, Ss Swivel Adjustable Elbow Manufacturer in Bursa, Cs Swive Elbow In Istanbul, Turkey.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Adjustable Locknut Elbow Supplier in Istanbul, Turkey

You’ll find Adjustable Locknut Elbows widely used across various sectors, including chemical processing, petrochemical, oil and gas, pharmaceuticals, power generation, and marine industries. They play a crucial role in changing the direction of piping systems, offering flexibility in tight spaces, and ensuring the safe and efficient operation of pipelines and instrumentation systems. With their versatility, reliability, and durability, adjustable locknut elbows are essential for applications that demand precise alignment, high performance, and long-term operational safety.

Adjustable Locknut Elbow Uses

Adjustable locknut elbows are commonly used in electrical circuit systems to connect the conduit at different angles while maintaining a secure, adjustable connection and are particularly useful in tight or awkward standard locations rigid fittings cannot allow for changes in direction. The locknut keeps the elbow securely in place and prevents it from loosening due to vibration or movement. These fittings are used in industrial, commercial and residential wiring systems to provide flexibility during installation while ensuring continuous ground clearance and protecting the wiring from damage
