Hydraulic Equal Tee

Home > Hydraulic Equal Tee

Ayhan Tube Fittings is a leading manufacturer and supplier of high quality tube fittings and Hydraulic Equal Tees in Istanbul, Turkey. With our many years of expertise, we specialize in providing robust and precision engineered fittings for a variety of industrial applications, ensuring efficiency and reliability. Our same hydraulic tees are engineered to meet the highest standards, providing pressure resistance and seamless connection. At Ayhan Tube Fittings, we are committed to providing the best products, exceptional customer service and competitive pricing to meet the needs of our customers.

Hydraulic Equal Tee Supplier in Istanbul, CS Hydraulic Equal Tee Manufacturer in Ankara, Turkey, DIN 2353 Hydraulic Tee Exporter in Antalya, Hydraulic Equal Tee Assembled & Un Assembled Supplier in Istanbul, CS Hydraulic Equal Tee Exporter in İzmir, DIN 2353 Hydraulic Tee Manufacturer in Ankara, Turkey, Hydraulic Equal Tee Manufacturer in Antalya

Hydraulic Equal Tees are usually made of carbon steel, stainless steel, or steel alloys for durability and corrosion resistance. Its mechanical properties include high tensile strength, good ductility and excellent stress resistance. The tee is designed to evenly distribute or combine hydraulic flow in three directions at a 90-degree angle. The main advantages are more efficient water distribution, reduced piping pressure, ease of installation and flexibility in high pressure systems. Its rugged construction ensures reliable performance in complex mechanical, hydraulic and mechanical applications.

Hydraulic Equal Tee Specifications

STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20
MATERIAL
SERIES	LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
CONNECTIONS	TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE
CONNECTIONS	WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL
BODY TYPE	FORGED, BAR STOCK
SURFACE	CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED,
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	STEEL – (-40* C TO 120C) ,STAINLESS STEEL – (-60C TO 400C) BRASS – (-60C TO 175*C)
EQUIVALENT BRANDS	PARKER, HY-LOK , DK-LOK , STAUFF, HYDAC , VOSS
APPLICATIONS & INDUSTRIES	CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT

Top Hydraulic Equal Tee Manufacturing Company in Istanbul

At Ayhan Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Equal Tee in Istanbul, Turkey. Our advanced manufacturing facilities, strategically positioned in the Turkey, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Hydraulic Equal Tee

Dimensions of Hydraulic Equal Tee

Thread	CH	L1	L2	T	Pressure PN	Weight kg 100pcs	Series
Thread F1	mm	mm	mm	mm	bar
12×1,5	12	12	27	6	315	6,3	L
12×1,5	12	12	27	6	315	6,3	L
14×1,5	12	14	29	8	315	8,5	L
14×1,5	12	14	29	8	315	8,5	L
16×1,5	14	15	30	10	315	11,5	L
16×1,5	14	15	30	10	315	11,5	L
18×1,5	17	17	32	12	315	15,0	L
18×1,5	17	17	32	12	315	15,0	L
22×1,5	19	21	36	15	315	24,5	L
22×1,5	19	21	36	15	315	24,5	L
26×1,5	24	23,5	40	18	315	35,8	L
26×1,5	24	23,5	40	18	315	35,8	L
30×2	27	27,5	44	22	160	47,9	L
30×2	27	27,5	44	22	160	47,9	L
36×2	36	30,5	47	28	160	74,5	L
36×2	36	30,5	47	28	160	74,5	L
45×2	41	34,5	56	35	160	100,0	L
45×2	41	34,5	56	35	160	100,0	L
52×2	50	40	63	42	160	150,0	L
52×2	50	40	63	42	160	150,0	L
14×1,5	12	16	31	6	630	11,0	S
14×1,5	12	16	31	6	630	11,0	S
16×1,5	14	17	32	8	630	14,2	S
16×1,5	14	17	32	8	630	14,2	S
18×1,5	17	17,5	34	10	630	19,1	S
18×1,5	17	17,5	34	10	630	19,1	S
20×1,5	17	21,5	38	12	630	24,3	S
20×1,5	17	21,5	38	12	630	24,3	S
22×1,5	19	22	40	14	630	30,2	S
22×1,5	19	22	40	14	630	30,2	S
24×1,5	24	24,5	43	16	400	39,8	S
24×1,5	24	24,5	43	16	400	39,8	S
30×2	27	26,5	48	20	400	60,0	S
30×2	27	26,5	48	20	400	60,0	S
36×2	36	30	54	25	400	112,0	S
36×2	36	30	54	25	400	112,0	S
42×2	41	35,5	62	30	400	146,0	S
42×2	41	35,5	62	30	400	146,0	S
52×2	50	41	72	38	315	206,0	S
52×2	50	41	72	38	315	206,0	S

Hydraulic Equal Tee Assembled & Un Assembled Manufacturer in Ankara, SS Hydraulic Equal Tee Exporter in Istanbul, Hydraulic Reducing Tee Exporter in Antalya, DIN 2353 Hydraulic Tee Supplier in İzmir, Hydraulic Equal Tee Assembled & Un Assembled Exporter in Bursa, Hydraulic Reducing Tee Supplier in Bursa, Hydraulic Equal Tee Stockist in Ankara, Turkey

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Hydraulic Equal Tee in Istanbul, Turkey

Ayhan Tube Fittings is a leading supplier and stockist of premium Hydraulic Equal Tee in Istanbul, Turkey. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hydraulic Equal Tee Uses

Hydraulic Equal Tee are widely used in hydraulic systems to split or disperse flow at a 90-degree angle. They are important in the oil and gas, fuel, automotive, and construction industries to guide flow between pipelines. These tees can effectively distribute or connect fluids, balancing pressure and flow in complex systems. Typical applications include hydraulic engines, energy generation, and water transfer systems, where they contribute to continuous operation, reduce system stress, and improve overall water consumption efficiency in high-pressure environments.
