Ayhan Tube Fittings, located in Istanbul, Turkey, has built a solid reputation as a reliable manufacturer and supplier of Inconel 625 Tube Fittings, catering to a variety of industries with top-notch products. The company prides itself on precision engineering and adherence to international standards, delivering fittings that are renowned for their durability, corrosion resistance, and dependability even in extreme conditions. Each product from Ayhan Tube Fittings goes through rigorous quality checks, serving sectors like oil and gas, chemical processing, and marine applications. With a strong focus on customer service, prompt deliveries, and competitive pricing, Ayhan Tube Fittings has established itself as a leader in the specialty tube fittings market.
Inconel 625 Tube Fittings are primarily made up of nickel (at least 58%), chromium (20–23%), molybdenum (8–10%), niobium (3.15–4.15%), along with trace amounts of iron, titanium, and cobalt. This unique blend provides exceptional resistance to oxidation and corrosion, even in the toughest environments. On the mechanical side, Inconel 625 boasts impressive tensile strength, yield strength, and creep resistance at high temperatures. With outstanding fatigue strength, weldability, and toughness across a wide temperature range, these tube fittings are perfect for demanding industrial applications where durability and performance are key.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6010 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Equivalent To | SWAGELOK, PARKER, DK-LOK, HOKE |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application | |
| Material Test Certificates (MTC) for Tube Fitting as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Inconel 625 | N06625 | 2.4856 | NC22DNB4M | NiCr22Mo9Nb | NCF 625 | NA 21 | ХН75МБТЮ | ЭИ602 |
Inconel 625 Tube Fittings find extensive use in industries that require superior resistance to harsh environments and high-pressure situations. In the oil and gas industry, they are utilized in offshore drilling, subsea equipment, and pipelines that face seawater exposure. The chemical and petrochemical sectors depend on them for managing corrosive fluids and acids. In aerospace, Inconel 625 is prized for its strength in high-temperature applications, such as jet engines and exhaust systems. Moreover, marine engineering, nuclear power plants, and pollution control systems all benefit from the long-lasting durability and service life of these specialized tube fittings.
Contact us to get a quick quote for your requirement.
Inconel 625 Tube Fittings are used in applications where resistance to high temperatures, corrosion and oxidation is very important. Because they can withstand extreme temperatures they are ideal for aerospace components such as jet engines, exhaust systems and turbine seals In marine engineering these components provide excellent protection against seawater corrosion, and making them for offshore platforms and underwater equipment In addition to being suitable, they are widely used in chemical plants to prevent corrosion by acid gases, providing durability and reliability if operating in areas severe
Please feel free to contact us if you need any further information or for enquiry.
