Monel Condensate Pots

Home > Monel >Monel Condensate Pots

Ayhan Tube Fittings, located in Istanbul, Turkey, has built a solid reputation as a reliable manufacturer and supplier of top-notch Monel Condensate Pots. These pots are crafted to deliver efficiency and durability in critical industrial settings. Thanks to their state-of-the-art production facilities and a commitment to international standards, the company produces condensate pots that perform exceptionally well, even in the toughest environments. Renowned for their corrosion resistance, strength, and dependability, Ayhan Tube Fittings’ Monel Condensate Pots are a go-to choice for industries worldwide, providing long-lasting service and precise engineering tailored to the oil, gas, chemical, and marine sectors.

Monel Type A Condensate Pot with Galvanized Plating Manufacturer Istanbul, Monel® Alloy Type B Condensate Pot with Zinc Plating Dealer Ankara, Monel Type C Condensate Pots with 4 Ports Dealers İzmir, Monel Type A Condensate Pots with 2 Ports Exporter In Antalya, UNS N04400 Type B Condensate Pots Exporter In Bursa, Monel Type C Condensate Pot with Zinc Plating Exporter In Istanbul, Turkey.

Monel Condensate Pots are primarily made from nickel and copper, with trace amounts of iron and manganese, which gives them remarkable resistance to seawater, steam, and other corrosive conditions. They boast impressive mechanical properties, including high tensile strength, toughness, and durability, even at elevated temperatures. Additionally, these pots are designed to resist stress corrosion cracking, pitting, and oxidation, making them a trustworthy option for demanding operations. Their sturdy design and metallurgical stability ensure they perform consistently well, even in challenging industrial processes.

Monel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Chemical Compositions Of Monel Alloy Condensing Pot

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel Alloy Condensing Pot	0.30 max	2.00 max	0.50 max	0.024 max	28.00 – 34.00	2.50 max	63.00 min

Sizing Of Monel Alloy Condensing Pot

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Top Monel Condensate Pots Manufacturing Company in Istanbul

At Ayhan Tube Fittings, we are the largest supplier, manufacturer, and exporter of Monel Condensate Pots in Istanbul, Turkey. Our advanced manufacturing facilities, strategically positioned in the Turkey, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Monel Condensate Pots

Monel Condensate Pot Type A Price in Istanbul, Monel Type B Condensate Pot with Red Oxide Coated Manufacturer Supplier in Ankara, Monel Condensate Pot Type C Manufacturer in İzmir, Monel® Alloy Type A Condensate Pot with Red Oxide Coated Price in Antalya, K500 Monel Condensate Pots Type B Manufacturer in Bursa, 400 Monel Type C Condensate Pot Dealer In Istanbul, Turkey.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Monel Condensate Pots Supplier in Istanbul, Turkey

Ayhan Tube Fittings is a leading supplier and stockist of premium Monel Condensate Pots in Istanbul, Turkey. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Monel Condensate Pots Uses

These Monel Condensate Pots find extensive use in industries that require precise pressure measurement and protection for instrumentation against steam, condensate, and debris. They are commonly utilized in power plants, refineries, petrochemical facilities, and offshore platforms, where reliability in harsh conditions is crucial. Acting as reservoirs, these pots collect condensate and help separate impurities, ensuring accurate readings and safeguarding sensitive equipment. Their outstanding corrosion resistance makes them ideal for marine and chemical processing applications, promising a long service life in aggressive operating environments.
