Pressure Gauge Connector

Home > Pressure Gauge Connector

Ayhan Tube Fittings, based in Istanbul, Turkey, is a well-respected manufacturer and supplier of top-notch Pressure Gauge Connectors, designed for accurate and secure connections in instrumentation. With a strong emphasis on innovation, durability, and adherence to international standards, Ayhan provides dependable solutions for monitoring and controlling pressure in essential fluid and gas systems. Their Pressure Gauge Connectors are crafted to guarantee leak-free and vibration-resistant links between pressure gauges and process lines. Trusted by experts in the oil & gas, chemical, pharmaceutical, and industrial automation sectors, Ayhan merges precision manufacturing with sturdy materials to fulfill the rigorous demands of pressure instrumentation applications around the globe.

Pressure Gauge Connector Supplier in Istanbul, Hydraulic Pressure Gauge Connector Price List in Ankara, Pressure Gauge Connectors Dn63 Manufacturer in İzmir, Reducer In Antalya, SS Pressure gauge connector Exporter in Ankara, Pressure Gauge Connector Manufacturer in Bursa, Pressure Gauge Connectors Dn63 In Istanbul, Turkey.

Ayhan’s Pressure Gauge Connectors are generally made from corrosion-resistant materials like stainless steel (SS 316/316L), brass, or carbon steel. The stainless steel variants offer remarkable mechanical strength, boasting a tensile strength of 515–620 MPa and a yield strength of about 205 MPa. These connectors excel in corrosion resistance, can handle high pressure ratings (up to 6,000 psi), and provide excellent sealing capabilities. Precision machining guarantees tight dimensional tolerances and secure fittings, even under vibration and thermal stress. All connectors meet ASTM and ISO standards, making them ideal for harsh environments and long-lasting service in pressure monitoring systems.

Pressure Gauge Connector Specifications

STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	MS, CS, SS 304, SS 304L, SS 316, SS 316L, SS 316TI ( 1.4571), BRASS, COPPER, DUPLEX, SUPER DUPLEX, INCONEL, MONEL, HASTELLOY, 904L, 6MO, TITANIUM, ALUMINUM, ALLOY 20
MATERIAL
SERIES	LL- LOW PRESSURE, L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
BODY TYPE	BAR STOCK
SURFACE	CARBON STEEL -TRIVALENT ZINC PLATED, YELLOW PLATTING, BLACK PHOSPHATE,
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH

Pressure Gauge Connector Manufacturing Company in Istanbul

At Ayhan Tube Fittings, we are the largest supplier, manufacturer, and exporter of Pressure Gauge Connector in Istanbul, Turkey. Our advanced manufacturing facilities, strategically positioned in the Turkey, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Pressure Gauge Connector

Pressure Gauge Connectors Dn63

CONNECTORS FOR PRESSURE GAUGE DN63
Thread type	Brass	Max pressure	AISI316	Max pressure
G1/8B	684	630 bar	692	1000 bar
G1/4B G1/4B DIN	675 5635	800 bar 800 bar	688 3828	1250 bar 1250 bar
G3/8B G3/8B w/spigot	680 6379	1000 bar 1000 bar	141	1600 bar
G1/2B	690	1250 bar	693	1600 bar
1/4 BSP T			3399	1250 bar
1/4 flare (7/16-UNF20(SAE)) 3/8 flare (5/8-18 UNF(SAE))	687 6931	800 bar 1000 bar	3219	1250 bar
1/8 NPT 1/4 NPT 1/2 NPT	4047 681	630 bar 800 bar	5158 4050 4051	1000 bar 1250 bar 1600 bar
Throttle screw – Standard damping – Powerfull damping	. 152 2129		. 1427
M10x0,75			1804
M12x1,5 (for Ø6mm tube, compr. gland)			3872
			Carbon steel
Union – M12x1,5 Olive – Ø6 mm			1387 1388
Gaket – PTFE	. 0405-004
Extra gasket G1/4 G3/8 G1/2	Fiber H143 H144 H145	Copper 8760 . 8637

SS Pressure gauge connector Exporter in Istanbul, Reducer Price List in Ankara, Pressure Gauge Connectors Dn63 Manufacturer in İzmir, Hydraulic Pressure Gauge Connector In Antalya, Pressure Gauge Connector Supplier in Ankara, Reducer Manufacturer in Bursa, SS Pressure gauge connector In Istanbul, Turkey.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Pressure Gauge Connector Supplier in Istanbul, Turkey

Ayhan Tube Fittings is a leading supplier and stockist of premium Pressure Gauge Connector in Istanbul, Turkey. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Pressure Gauge Connector Uses

Pressure Gauge Connectors play a vital role in securely attaching pressure gauges to pipelines, tanks, pumps, or instrumentation panels. Ayhan’s connectors are extensively utilized in oil & gas, petrochemical, pharmaceutical, water treatment, and HVAC systems, where precise pressure readings are crucial. These fittings facilitate easy installation, removal, and maintenance of gauges without causing disruptions.
