Ayhan Tube Fittings, based in Istanbul, Turkey, stands out as a top manufacturer and supplier of **Stainless Steel 316 Ball Valves**. They specialize in delivering high-quality solutions for precise fluid control in various industrial settings. Renowned for their precision engineering and dependable performance, these ball valves are designed to withstand harsh environments, offering exceptional corrosion resistance and durability. Built to meet international standards, these valves promise long-lasting operation, safety, and efficiency. Thanks to their cutting-edge manufacturing technology and a strong focus on customer satisfaction, Ayhan Tube Fittings has built a solid reputation for providing stainless steel 316 ball valves that enhance system performance and ensure reliable service across a diverse range of industries.
Crafted from premium 316 stainless steel, these ball valves boast outstanding resistance to corrosion, chemical exposure, and high temperatures. They are known for their impressive mechanical strength, durability, and stability even under extreme conditions. With smooth operation and reliable sealing, they are perfect for continuous use in demanding industrial processes. Their sturdy design minimizes maintenance needs while safeguarding connected systems and ensuring effective fluid control.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
| Grade | Mn | C | S | Mo | N | Si | P | Cr | Ni | |
| 316 | Minimum | – | – | – | 2.00 | – | – | 0 | 16.0 | 10.0 |
| Maximum | 2.0 | 0.08 | 0.03 | 3.00 | 0.10 | 0.75 | 0.045 | 18.0 | 14.0 | |
| 316H | Minimum | 0.04 | 0.04 | – | 2.00 | – | 0 | – | 16.0 | 10.0 |
| Maximum | 0.10 | 0.10 | 0.03 | 3.00 | – | 0.75 | 0.045 | 18.0 | 14.0 |
|
Grade |
Yield Strength |
Tensile Strength |
Elongation (%) |
Reduction of Area (%) |
Hardness Max |
|
Min (Mpa) |
Min (Mpa) |
Min |
Min (50mm) |
HB |
|
|
Stainless Steel 316 Valves |
170 |
485 |
30 |
50 |
217* |
|
Stainless Steel 316 Valves |
205 |
515 |
30 |
50 |
217* |
| Grade | British | Euronorm | UNS No | SS | JIS | ||
| European Standards | British Standards | DIN No | Name | ||||
| 316 | 58H, 58J | 316S31 | 1.4401 | X5CrNiMo17-12-2 | S31600 | 2347 | SUS 316 |
| 316H | – | 316S51 | – | – | S31609 | – | – |
Stainless Steel 316 Ball Valves find their place in various sectors, including chemical processing, petrochemicals, pharmaceuticals, marine, food and beverage, and power generation. They play a crucial role in managing and regulating the flow of liquids and gases, which is vital for system safety and operational efficiency. With their corrosion resistance, durability, and reliable sealing, these valves are the go-to choice for high-performance applications that demand long-term reliability, precise flow control, and safe operation in aggressive or corrosive environments.
Contact us to get a quick quote for your requirement.
Stainless steel 316 round valves are widely used in various industries due to their excellent corrosion resistance, durability and high strength. They are ideal for high pressure water, chemical and high temperature applications, making them suitable for the oil, gas, chemical industry, food, beverage and pharmaceutical industries These valves provide reliable coverage capabilities so, make sure there is minimal leakage and maintains a smooth flow. Furthermore, their ease of use and low maintenance requirements make them a desirable choice for industrial and commercial pipelines
Please feel free to contact us if you need any further information or for enquiry.
