Ayhan Tube Fittings, located in Istanbul, Turkey, is a reputable manufacturer and supplier of **Stainless Steel 316 Hydraulic Fittings**. They specialize in providing top-notch solutions for reliable fluid transport in hydraulic systems across various industries. Renowned for their precision engineering and sturdy construction, the company creates hydraulic fittings that guarantee leak-free, durable connections even under high pressure and in corrosive environments. Built to meet international standards, these fittings promise long-lasting performance, safety, and operational efficiency. Thanks to their cutting-edge production technology and a strong focus on customer satisfaction, Ayhan Tube Fittings has built a solid reputation for delivering stainless steel 316 hydraulic fittings that boost system reliability and performance in critical applications.
The Stainless Steel 316 Hydraulic Fittings are crafted from high-quality 316 stainless steel, which offers outstanding corrosion resistance, impressive mechanical strength, and excellent chemical stability. They maintain their shape, provide precise sealing, and can handle high-pressure operations, ensuring secure, leak-free performance. Their robust design allows for easy assembly, requires minimal maintenance, and boasts a long service life, making them perfect for demanding hydraulic applications.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | SS 316 ,SS 316L |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| TEMPERATURE | STAINLESS STEEL 316 – (-60*C TO 400*C) |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
Grade | Mn | C | S | Mo | N | Si | P | Cr | Ni | |
316 | Minimum | – | – | – | 2.00 | – | – | 0 | 16.0 | 10.0 |
Maximum | 2.0 | 0.08 | 0.03 | 3.00 | 0.10 | 0.75 | 0.045 | 18.0 | 14.0 | |
316H | Minimum | 0.04 | 0.04 | – | 2.00 | – | 0 | – | 16.0 | 10.0 |
Maximum | 0.10 | 0.10 | 0.03 | 3.00 | – | 0.75 | 0.045 | 18.0 | 14.0 |
Grade | Elong (% in 50mm) min | Yield Str 0.2% Proof (MPa) min | Tensile Str (MPa) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
316 | 40 | 205 | 515 | 95 | 217 |
316H | 40 | 205 | 515 | 95 | 217 |
Grade | British | Euronorm | UNS No | SS | JIS | ||
European Standards | British Standards | DIN No | Name | ||||
316 | 58H, 58J | 316S31 | 1.4401 | X5CrNiMo17-12-2 | S31600 | 2347 | SUS 316 |
316H | – | 316S51 | – | – | S31609 | – | – |
These fittings are widely utilized in industries such as chemical processing, petrochemical, oil and gas, marine, power generation, and industrial machinery. They play a crucial role in connecting hydraulic lines, managing fluid flow, and ensuring the safe and efficient operation of hydraulic systems. With their corrosion resistance, strength, and reliability, stainless steel 316 hydraulic fittings are essential for applications that demand high performance, durability, and long-term operational safety.
Contact us to get a quick quote for your requirement.
Stainless steel 316 hydraulic fittings are widely used in applications requiring excellent corrosion resistance. Especially in marine, chemical processing, oil and gas, petrochemical applications and as resistant to chloride and chemicals a its high durability makes it ideal for marine environments, salt marshes and coastal habitats . These materials are also suitable for food and beverage processing, medical devices and water treatment. Where cleanliness and durability are important In addition they perform well in high temperature and pressure conditions, and provide stainless steel 316 hydraulic. Fittings are a reliable choice for connecting pipe and tubing in demanding hydraulic systems.
