Constructed from high-quality materials such as stainless steel, carbon steel, and nickel alloys, Swivel Pipe Adaptors are tailored to meet specific application needs. Their innovative design includes a rotating connection that allows pipes to swivel, making alignment adjustments easier and reducing stress on piping systems. Mechanically, they boast high tensile and yield strength, pressure resistance, and durability in extreme temperatures and pressures. With excellent corrosion resistance and sturdy construction, these adaptors promise a long service life and minimal maintenance, making them ideal for demanding industrial environments.
Constructed from high-quality materials such as stainless steel, carbon steel, and nickel alloys, Swivel Pipe Adaptors are tailored to meet specific application needs. Their innovative design includes a rotating connection that allows pipes to swivel, making alignment adjustments easier and reducing stress on piping systems. Mechanically, they boast high tensile and yield strength, pressure resistance, and durability in extreme temperatures and pressures. With excellent corrosion resistance and sturdy construction, these adaptors promise a long service life and minimal maintenance, making them ideal for demanding industrial environments.
|
Mcneil Instruments PART # |
END SIZE |
C2 HEX BODY (in.) |
W4 (in.) |
Dynamic Pressure (x 1,000 PSI) |
||||
|
1 UN/UNF-2A |
2 NPSM |
|||||||
|
-S |
-SS |
-B |
||||||
| 0507-4-2 |
7/16 – 20 |
1/8 – 27 |
9/16 |
1.21 |
6.0 |
6.0 |
3.3 |
|
| 0507-4-4 |
7/16 – 20 |
1/4 – 18 |
9/16 |
1.32 |
6.0 |
6.0 |
3.3 |
|
| 0507-5-4 |
1/2 – 20 |
1/4 – 18 |
5/8 |
1.32 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-4 |
9/16 – 18 |
1/4 – 18 |
11/16 |
1.35 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-6 |
9/16 – 18 |
3/8 – 18 |
11/16 |
1.37 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-8 |
9/16 – 18 |
1/2 – 14 |
3/4 |
1.57 |
5.0 |
5.0 |
3.3 |
|
| 0507-8-4 |
3/4 – 16 |
1/4 – 18 |
7/8 |
1.43 |
6.0 |
6.0 |
3.3 |
|
| 0507-8-6 |
3/4 – 16 |
3/8 – 18 |
7/8 |
1.45 |
6.0 |
6.0 |
3.3 |
|
| 0507-8-8 |
3/4 – 16 |
1/2 – 14 |
7/8 |
1.56 |
5.0 |
5.0 |
3.3 |
|
| 0507-8-12 |
3/4 – 16 |
3/4 – 14 |
1 |
1.79 |
4.0 |
4.0 |
2.6 |
|
| 0507-10-6 |
7/8 – 14 |
3/8 – 18 |
1 |
1.59 |
5.0 |
5.0 |
3.3 |
|
| 0507-10-8 |
7/8 – 14 |
1/2 – 14 |
1 |
1.73 |
5.0 |
5.0 |
3.3 |
|
| 0507-10-12 |
7/8 – 14 |
3/4 – 14 |
1 1/4 |
1.88 |
4.0 |
4.0 |
2.6 |
|
| 0507-12-8 |
1 1/16 – 12 |
1/2 – 14 |
1 1/4 |
1.88 |
5.0 |
5.0 |
3.3 |
|
| 0507-12-12 |
1 1/16 – 12 |
3/4 – 14 |
1 1/4 |
1.97 |
4.0 |
4.0 |
2.6 |
|
| 0507-12-16 |
1 1/16 – 12 |
1 – 11 1/2 |
1 1/2 |
2.12 |
3.0 |
3.0 |
1.9 |
|
| 0507-14-12 |
1 3/16 – 12 |
3/4 – 14 |
1 3/8 |
1.97 |
4.0 |
4.0 |
2.6 |
|
| 0507-16-12 |
1 5/16 – 12 |
3/4 – 14 |
1 1/2 |
1.90 |
4.0 |
4.0 |
2.6 |
|
| 0507-16-16 |
1 5/16 – 12 |
1 – 11 1/2 |
1 1/2 |
2.12 |
3.0 |
3.0 |
1.9 |
|
| 0507-20-16 |
1 5/8 – 12 |
1 – 11 1/2 |
1 7/8 |
2.20 |
3.0 |
3.0 |
1.9 |
|
| 0507-20-20 |
1 5/8 – 12 |
1 1/4 – 11 1/2 |
1 7/8 |
2.21 |
2.5 |
2.5 |
1.6 |
|
| 0507-24-24 |
1 7/8 – 12 |
1 1/2 – 11 1/2 |
2 1/8 |
2.39 |
2.0 |
2.0 |
1.3 |
|
| 0507-32-32 |
2 1/2 – 12 |
2 – 11 1/2 |
2 3/4 |
2.49 |
1.5 |
1.5 |
1.0 |
|
At Ayhan Tube Fittings, we are the leading supplier, manufacturer, and exporter of Swivel Pipe Adaptor in Istanbul, Turkey. Our state-of-the-art manufacturing facilities, strategically located in the Turkey, empower us to provide high-quality solutions tailored to your specific requirements. With an extensive inventory of various premium materials, we are well-equipped to meet your needs efficiently. Our dedication to excellence and operational efficiency ensures we consistently maintain available stock, making us your trusted partner for reliable Union Cross fittings in various applications.
Swivel Pipe Adaptors find extensive use in industries that require flexible and secure piping connections. In the oil and gas sector, they are essential for pipelines, drilling rigs, and refineries, facilitating fluid transfer and system alignment. Chemical and petrochemical plants rely on them to handle corrosive fluids while ensuring reliable performance. Marine applications benefit from their resistance to seawater and vibrations, while the power generation and water treatment sectors utilize them in high-pressure piping systems. Their versatility, durability, and straightforward installation make Swivel Pipe Adaptors a go-to choice for many industrial setups.
Contact us to get a quick quote for your requirement.
Swivel pipe adaptors are versatile components widely used in various applications. They are primarily employed in plumbing systems to connect pipes at different angles without causing stress or leaks. In hydraulic systems, these adaptors facilitate fluid transfer, allowing for smooth movement and rotation, which is essential for machinery and equipment. They are also commonly used in irrigation systems to connect hoses and fittings, ensuring efficient water distribution. Additionally, swivel pipe adaptors are utilized in automotive and industrial applications, providing flexibility and durability for safe and effective fluid handling.
